Hoffman Watchman Condensate Pump, Motor, & Receiver Package
Manufacturer
Hoffman |
Manufacturer Part No
160 |
|
|
|
| Hoffman condensate units are used to return condensate to the
boiler. Applications include residential, commercial, institutional, and
industrial steam heating, and industrial processing; dry cleaning plants,
chemical refineries, wood pulp paper processing, textile mills, and
manufacturing facilities. Features
- For 6,000, 8,000 and 12,000 sq. ft. EDR systems*
- Available with pumps in simplex or duplex design
- Low height NPT inlet for easy return line piping
- Separate NPT connections provide a secondary vent
for safe operation
- NPT drain connection
- Double pole float switch - simplex models
- Mechanical alternator - duplex models
- Easy to install
- Easy to service with vertical pull out pumps
- 100% factory tested as a complete unit
- Series WC includes cast iron receiver with 20 year
warranty against corrosion
- Series WCS includes steel receiver
- Optional equipment:
— Inlet basket strainer
— Y-strainer
— Control panels for wall mounting
- Pump seal maximum temperature 225°F (107°C)
- 2' NPSH pumps capable of handing 209°F (98°C)
condensate
|
 |
 |
|
